Specifications + Dimensions

AC Output
60 Hz, 1800 RPM,
3 Ph, 0.8 PF,
120-208V / 125A, 120V / 300A
36 kW
50 Hz, 1500 RPM,
3 Ph, 0.8 PF,
220V / 105A
32 kW
OptionalSingle Phase
with 1.0 PF
Voltage Regulation+/- 1%
(Deratings: 3% per 1000 ft. over 500 feet above sea level. 1.5% for every 10° over 77°F)
Lugger L944 Engine
TypeVertical inline
4 cylinder diesel
Displacement:203 cubic in
(3.33 ltr)
Bore/Stroke:3.70/4.72 in
(94/120 mm)
AspirationTurbocharged
Fuel SystemBosch type
inline injection
pump
Approximate fuel use:
1800 RPM
@ full load
2.8 gph
(8.6 lph)
1800 RPM
@ half load
1.5 gph
(5.3 lph)
1500 RPM
@ full load
2.3 gph
(7.4 lph)
1500 RPM
@ half load
1.2 gph
(4.2 lph)
(Actual fuel consumption will vary depending on operating conditions.)
Installation Data
Fuel inlet and return1/4 inch NPT
Weight and Height
Length:64.8 in
(1647 mm)
Width:25.6 in
(650 mm)
Height:35.8 in
(910 mm)
Approximate
Dry Weight:
1390 lbs
(630 kg)

Note:

Information and dimensions are subject to change without notice.

Contact dealer for most current installation drawings.

Standby Emergency Duty Only

Features + Benefits

  • Lugger, four cycle, 4 cylinder, liquid cooled, turbocharged, overhead valve industrial duty diesel engine.
  • Two valves per cylinder.
  • Double wall oil pan.
  • Crankshaft is induction hardened, forged carbon steel; stronger than cast iron.
  • Helical cut and ground carbon steel timing gears reduce noise.
  • Cross flow head for efficient breathing.
  • Liquid cooled with radiator and pusher cooling fan. Radiator shroud and fan hand guard.
  • Direct injection with glow plugs.
  • Bosch-type in-line injection pump with 5% mechanical governor for close AC output frequency control.
  • Pintle type injectors.
  • Mechanical fuel lift pump with hand primer.
  • Large spin-on fuel filter.
  • Flexible fuel lines routed to base.
  • Stop solenoid controls fuel rack, not throttle, for fast engine shutdowns
  • Meets US EPA interim Tier IV emission requirements.
  • Large air cleaner with replaceable filter element.
  • Full flow, spin-on oil filter.
  • DC system uses reliable relays instead of unrepairable printed circuit board.
  • 12 volt starter and battery charging alternator with regulator.
  • Standard panel: J-box mounted S-1B has hour meter, shutdown bypass, stop-start switch and preheat switch.
  • Low oil pressure and high coolant temperature shutdowns are standard.
  • Steel base frame provides rigid support and makes installation easy.
  • Vibration mounts isolate engine vibration for smooth, quiet operation.
  • Long life, Imron® enamel finish for excellent service visibility.
  • Operator’s and parts manuals standard. Optionally available on CD-ROM.
  • Each set is test run on load bank.
  • Steel base frame provides rigid support and makes installation easy.
  • Vibration mounts isolate engine vibration for smooth, quiet operation.
  • Long life, Imron® enamel finish for excellent service visibility.
  • Operator’s and parts manuals standard. Optionally available on CD-ROM.
  • Each set is test run with load.
  • Industry-best, transferrable warranty.
